2010 Honda Stateline
Request a Quote Financing Calculator Request a Brochure Financing Form
Request a Quote Financing Calculator Request a Brochure Financing Form
  • OEM Overview
  • Specifications
  • Compare Models
  • Current Promotions

Overview

 Print Brochure

A lot of words come to mind when you first glance our all-new line of 1300 Customs. Part chopper, part Pro Street custom, and all Honda, this trio of radical machines has arrived—and Main Street will never be the same.


Introducing the 2010 Honda Stateline. Call it the perfect fusion of traditional and progressive cruiser design, featuring all the classic cues that make the Fury and Sabre so cool, plus a few twists that are decidedly neo-retro, like deep, long fenders.


The brawny 1312cc liquid-cooled, fuel-injected 52º V-twin is a thing of beauty, too, with smooth, maintenance-free shaft final drive putting all that torque and power to the ground with effortless ease.


See what happens when you build a custom that’s equal parts old school and new. Then look no further than the Stateline.

  • Fuel-injected 1312cc, 52º V-twin engine
  • Shaft final drive
  • Available Spring 2010
Engine
  • Engine Type: 1312cc liquid-cooled 52° V-twin
  • Bore And Stroke: 89.5mm x 104.3mm
  • Induction: PGM-FI with automatic enrichment circuit, one 38mm throttle body
  • Ignition: Digital with 3-D mapping, two spark plugs per cylinder
  • Compression Ratio: 9.2:1
  • Valve Train: SOHC; three valves per cylinder
Drive Train
  • Transmission: Five-speed
  • Final Drive: Shaft
Chassis/Suspension/Brakes
  • Front Suspension: 41mm fork; 4.0 in. travel
  • Rear Suspension: Single shock; 3.9 in. travel
  • Front Brake: Single 336mm disc with twin-piston caliper
  • Rear Brake: 296mm disc with single-piston caliper
  • Front Tire: 140/80-17
  • Rear Tire: 170/80-15
Dimensions
  • Wheelbase: 70.1 in.
  • Seat Height: 26.7 in.
  • Curb Weight: 670 lbs. (Includes all standard equipment, required fluids and full tank of fuel—ready to ride.)
  • Rake: 33° (Caster Angle)
  • Trail: 118.0mm (4.6 in.)
  • Fuel Capacity: 4.4 gallons
Other
  • Emissions: Meets current EPA standards. California version meets current California Air Resources Board (CARB) standards and may differ slightly due to emissions equipment.
  • Available Colors: Black, Candy Dark Red
  • Model Id: VT1300CR
Factory Warranty Information
  • One Year: Transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.

Specifications

Engine
Engine Type 1312cc liquid-cooled 52° V-twin
Bore and Stroke 89.5mm x 104.3mm
Compression Ratio 9.2:1
Ignition Digital with 3-D mapping, two spark plugs per cylinder
Chassis
Front Suspension 41mm fork; 4.0 in. travel
Front Brakes Single 336mm disc with twin-piston caliper
Front Tire 140/80-17
Rear Suspension Single shock; 3.9 in. travel
Rear Brakes 296mm disc with single-piston caliper
Rear Tire 170/80-15
Dimensions
Fuel Capacity 4.4 gal.
Wheelbase 70.1 in.
Seat Height 26.7 in.
Trail 118.0mm (4.6 in.)
Rake 33° (Caster Angle)
Transmission
Transmission Five-speed
Final Drive Shaft
General
Colors Black, Candy Dark Red
Warranty One Year: Transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.

Compare Models

 Print








Year 2010
Manufacturer Honda
Model Stateline
Style Cruiser
MSRP* $11,699.00
Chassis
Front Suspension 41mm fork; 4.0 in. travel
Front Brakes Single 336mm disc with twin-piston caliper
Front Tire 140/80-17
Rear Suspension Single shock; 3.9 in. travel
Rear Brakes 296mm disc with single-piston caliper
Rear Tire 170/80-15
Dimensions
Dry Weight
Fuel Capacity 4.4 gal.
Wheelbase 70.1 in.
MPG
Seat Height 26.7 in.
Trail 118.0mm (4.6 in.)
Rake 33° (Caster Angle)
Engine
Engine Type 1312cc liquid-cooled 52° V-twin
Displacement
Bore and Stroke 89.5mm x 104.3mm
Cooling
Compression Ratio 9.2:1
Fuel System
Ignition Digital with 3-D mapping, two spark plugs per cylinder
General
Speedometer
Tachometer
Odometer
Colors Black, Candy Dark Red
Warranty One Year: Transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.
Transmission
Transmission Five-speed
Final Drive Shaft
